RENESIN
Where AI breakthroughs meet materials breakthroughs.
Renesin is developing the most advanced resins and laminates needed for AI PCBs and substrates with superior electrical, thermal, and processing performances.
THE PROBLEM
When compute accelerates, everything else must too.
As AI semiconductor chips reach unprecedented speeds, they generate intense heat and electrical stress. As a result, every piece of hardware needs to evolve to keep up.And right now, current materials are struggling. Only the most advanced, multi-layer PCBs and substrates can be used with AI chips, and there's not enough of those materials to go around.
OUR SOLUTION
A better resin system optimized for AI electronics
Our materials have industry-leading performances in key areas that matter including high thermal stability & ultra low transmission losses.Beyond performance, our materials have additional benefits that can help manufacturers and OEMs reduce costs, simplify processing, meet regulatory concerns, and minimize supply risks to enable production scaling faster and with greater confidence.We let the numbers speak for themselves below.
| Metric | Our Performance |
|---|---|
| Dielectric Constant | < 3 @ 10 GHz |
| Dielectric Loss | < 0.002 @ 10 GHz |
| Glass Transition Temperature | > 220 ° C |
| Water Absorption (after 14 days submerged) | < 0.5 % |
| Processing Capability & Viscosity | Tunable to exactly match ABF or lower |
| Toxicity Concerns | No PFAs or halogenated FRs used at all |
| Fire-Proof Concerns | Meets UL 94 V-0 standards |
| Supply Chain and Scalability Concerns | Low risk: uses abundant/available feedstocks |
| Cost Competitiveness | Reasonably priced way below PTFE/ceramics |
WHO WE ARE
Advanced materials, naturally engineered.
Renesin is the result of more than a decade of patented research spun out of collaborations between the US Army and other leading research institutions.Originally purposed for use in combat vehicles, these resins were found to have the exceptional properties needed for high-speed advanced PCBs and substrates.Our mission is to bring these breakthrough materials to the world’s most advanced technologies and transform how intelligence is powered, connected, and scaled.
CONTACT
Partner with us.
We are working to deliver these resins to market. Please reach out for collaboration opportunities, technical information, purchasing requests, and more.
Or send us an email at [email protected]
